MySQL Assignment Help | Restore MySQL Database Using MySQL Administrator

To run the code OPEN MYSQL Administrator, then click on Restore on the left of your screen.

Then click on open backup file and select the Employee_data.sql file.

After selecting the file click on Start Restore.

This process will create a database and tables.

Query1: Create three tables with relevant keys as suggested in the above diagram

Sol:-

Employee TABLE

DROP TABLE IF EXISTS `employee`;
CREATE TABLE `employee` (
 `employee_id` int(11) NOT NULL auto_increment,
  `Empname` varchar(25) NOT NULL,
 `Managerid` int(11) NOT NULL,
 `Dateofhire` date NOT NULL,
 `Jobname` varchar(15) NOT NULL,
 `Salary` decimal(10,2) NOT NULL,
 `department_id` int(11) NOT NULL,
 `DOB` date NOT NULL,
 `address` varchar(30) NOT NULL,
 PRIMARY KEY (`employee_id`),
 KEY `FK_employee_1` (`department_id`),
 CONSTRAINT `FK_employee_1` FOREIGN KEY (`department_id`) REFERENCES `department` (`department_id`)
) ENGINE=InnoDB AUTO_INCREMENT=1012 DEFAULT CHARSET=utf8;

Department TABLE

DROP TABLE IF EXISTS `department`;
CREATE TABLE `department` (
 `department_id` int(11) NOT NULL default '0',
 `Deptname` varchar(30) default NULL,
 `deptLocation` varchar(20) default NULL,
 `deptFloor` varchar(20) default NULL,
 PRIMARY KEY (`department_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8;

Salary TABLE


DROP TABLE IF EXISTS `salary`;
CREATE TABLE `salary` (
 `salary_level` int(11) NOT NULL default '0',
 `salarymin` int(11) default NULL,
 `salarymax` int(11) default NULL,
 PRIMARY KEY USING BTREE (`salary_level`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8;

Working with Queries

Query 2: Insert record of 10 employees in the employee table

Sol:-

INSERT INTO `employee` (`employee_id`,`Empname`,`Managerid`,`Dateofhire`,`Jobname`,`Salary`,`department_id`,`DOB`,`address`) VALUES
 (1001,'Mark',5001,'2000-08-01','PROGRAMMER','90000.00',902,'1994-05-23','101 Park Street LA'),
 (1002,'Mary',5002,'2017-08-23','TESTER','100000.00',902,'1990-04-27','101 Mark Street LA'),
 (1003,'Faith',5003,'2018-06-10','HR MANAGER','25000.00',903,'1988-05-05','101 Royal casa LA'),
 (1004,'Natalia',5004,'2018-05-26','MANAGER','96000.00',903,'1994-06-28','101 Wardha LA'),
 (1005,'Flynn',5005,'2019-12-27','ELECTRICAL ENGG','56000.00',904,'1987-07-29','101 Uchha Kuaa LA'),
 (1006,'Max',5006,'2016-07-19','IT MANAGER','19000.00',901,'1994-03-10','101 Lal Kuwa LA'),
 (1007,'Ronny',5007,'2018-03-18','PROGRAMMER','27000.00',902,'1990-02-08','101 Mandi House LA'),
 (1008,'Sheing',5008,'2014-09-28','ELECTRICAL ENGG','34000.00',904,'1991-01-05','101 Opera Street LA'),
 (1009,'Robert',5009,'2019-07-05','MAINTENANCE','78400.00',905,'1993-07-21','101 Nariman House LA'),
 (1010,'Kareena',5010,'2015-06-03','TESTER','120000.00',902,'1994-08-24','101 Henton house LA'),
 (1011,'Janet',5095,'2014-10-12','PROGRAMMER','90000.00',2011,'1994-08-24','101 Henton house LA');

Query 3: Insert record of 5 departments in the department table

Sol:-

INSERT INTO `department` (`department_id`,`Deptname`,`deptLocation`,`deptFloor`) VALUES
 (901,'IT','LONDON','1ST'),
 (902,'ENGG','LONDON','2ND'),
 (903,'HR','LONDON','3RD'),
 (904,'ELECTRICAL','LONDON','4TH'),
 (905,'MAINTENANCE','LONDON','5TH'),
 (2011,'PROGRAMMER1','PARIS','6TH');

Query 4: Insert record of 5 salary levels in the salary table

Sol:-

INSERT INTO `salary` (`salary_level`,`salarymin`,`salarymax`) VALUES

(1,15000,30000),

(2,30001,50000),

(3,50001,70000),

(4,70001,90000),

(5,90001,120000);

Query 5: Write a query to display the information about the employees in the employee

table

Sol:- SELECT * FROM employee e;
